Chorus, Flanger, and Phaser 047: Polysix Ensemble
803
047: Polysix Ensemble
This models the ensemble effect built into the classic
Korg PolySix programmable polyphonic synthesizer.
POLYSIX ENSEMBLE
Depth [0…100]
Sets the depth of the effect.
Source [Off…Tempo]
Selects the modulation source that will control the
effect depth.
Amount [+/–100]
Sets the amount by which the effect depth will be
modulated.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
048: Stereo Flanger
This effect gives a significant swell and movement of
pitch to the sound. It is more effective when applied to
a sound with a lot of harmonics. This is a stereo
flanger. You can add spread to the sound by offsetting
the phase of the left and right LFOs from each other.
FLANGER
Delay Time [msec] [0.0…50.0]
Sets the delay time from the original sound.
Depth [0…100]
Sets the depth of LFO modulation.
Feedback [+/–100]
This controls the intensity of the flanger effect. Positive
and negative values create different timbres.
Mixing the processed and dry signals via Wet/Dry will
enhance the effect. For maximum intensity, set
Feedback and Wet/Dry so that they are either both
positive or both negative; this emphasizes the flanger’s
harmonic peaks.
High Damp [%] [0…100]
This parameter sets the amount of damping of the
feedback in the high range. Increasing the value will
cut high-range harmonics.
LFO
Waveform [Triangle, Sine]
Selects the LFO Waveform.
Shape [+/–100]
Changes the curvature of the LFO Waveform. p.780.
Phase [degrees] [–180…+180]
Sets the LFO phase difference between the left and
right. See “Phase [degrees]” on page 779.
Frequency [Hz] [0.02…20.00]
This sets the LFO speed, in Hz. It applies only when
MIDI/Tempo Sync, below, is Off.
Source [Off…Tempo]
This selects a modulation source for the Frequency.
Amount [–20.00…+20.00]
This sets the Frequency modulation amount, in Hz.
MIDI/Tempo Sync [Check-box]
BPM [MIDI, 40.00…240.00]
Base Note [ … ]
Times [x1…x32]
When MIDI/Tempo Sync is on, the LFO speed is set by
BPM, Base Note, and Times, instead of Frequency. For
more information, see “MIDI/Tempo Sync” on
page 777.
Type [Individual, Common1, Common2]
This controls whether the effect uses its individual
LFO, or one of the Common FX LFOs. For more
information, see “LFO Type” on page 777.
Common LFO Phase Offset [degrees] [+/–180]
When Type is set to Common FX LFO 1 or 2, this lets
you offset the phase from the master LFO.
+
Polysix
Ensemble
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Flanger
Flanger
Left
Right
Feedback
LFO Shape
LFO Phase
LFO: Tri / Sine
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
