EQ and Filters 014: Stereo Exciter/Enhncr
775
014: Stereo Exciter/Enhncr
This effect is a combination of the Exciter, which adds a
punch to the sound and the Enhancer, which adds
spread and presence.
Pre EQ
Trim [0…100]
Sets the 2-band EQ input level.
LEQ Fc [Low, Mid-Low]
Selects the cutoff frequency (low or mid-low) of the
low-range equalizer.
LEQ Gain [dB] [–15.0…+15.0]
Sets the gain of the Low EQ.
HEQ Fc [High, Mid-High]
Selects the cutoff frequency (high or mid-high) of the
high-range equalizer.
HEQ Gain [dB] [–15.0…+15.0]
Sets the gain of the High EQ.
EXCITER
Emphasis Frequency [0…70]
This parameter sets the frequency to be emphasized.
Higher values will emphasize lower frequencies.
Source [Off…Tempo]
Selects the modulation source for the Emphasis
Frequency.
Amount [–70…+70]
Sets the amount of modulation of the frequency to be
emphasized
Blend [+/–100]
This parameter sets the depth (intensity) of the Exciter
effect. Positive values give a frequency pattern (to be
emphasized) different from negative values.
Source [Off…Tempo]
Selects the modulation source for the Exciter intensity.
Amount [+/–100]
Sets the modulation amount for the Exciter intensity.
ENHANCER
L Delay Time [msec] [0.0…50.0]
The L and R Delay Time parameters set the delay times
for the Enhancer’s left and right channels. Specifying
slightly different delay times for the left and right
channels will add a stereo image, depth, and width to
the sound.
R Delay Time [msec] [0.0…50.0]
Sets the delay time for the Enhancer’s right channel.
For more information, see “L Delay Time [msec],”
above.
Depth [0…100]
Sets the determines to what degree the Enhancer effect
is applied.
Source [Off…Tempo]
Selects the modulation source of the Enhancer width.
Amount [+/–100]
Sets the modulation amount of the Enhancer width.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
015: Stereo Isolator
This is a stereo effect that separates the input signal
into low, mid, and high-frequency bands, and controls
the volume of each band independently. For example
you can separately boost or cut the kick, snare, and hi-
hat sounds from a drum signal in realtime.
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
EQ Trim
LEQ HEQ
EQ Trim
Delay
Delay
Depth
D -mod
Exciter
Exciter
Enhancer
D -mod
D -mod
D -mod
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Trim
Isolator
Low
Mid
High
Trim
Low
Mid
High
