Effect Guide
822
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
070: Pitch Shifter BPM
This pitch shifter enables you to set the delay time to
match the song tempo.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
PITCH SHIFTER
Mode [Slow, Medium, Fast]
Switches Pitch Shifter mode. p.821.
Pitch Shift [1/2 steps] [–24…+24]
Sets the pitch shift amount in steps of a semitone. p.821
Fine [cents] [+/–100]
Sets the pitch shift amount in steps of one cent. p.821
Source [Off…Tempo]
Selects the modulation source for both Pitch Shift and
Fine.
Pitch Shift Amount [–24…+24]
Sets the modulation amount for Pitch Shift.
Fine Amount [+/–100]
Sets the modulation amount for Fine.
DELAY
BPM [MIDI, 40.00…240.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect. p.822
Time Over?> [---, OVER!]
The maximum delay time is 2,000msec. If the channel’s
combination of BPM, Base Note, and Times exceeds
this limit, the error message “OVER!” will appear. If
this occurs, change the delay time parameters so that
this message no longer appears.
Base Note [ …
Selects the type of notes to specify the delay time.
p.822.
Times [x1…x32]
Sets the number of notes to specify the delay time.
p.822.
Feedback Position [Pre, Post]
Switches the feedback connection. p.821.
Feedback [+/–100]
Sets the feedback amount. p.821.
High Damp [%] [0…100]
Sets the damping amount in the high range.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
DELAY: Times, Base Note, BPM
The delay time is the duration of Times number of
Base Note note values at the BPM tempo (or if BPM is
set to MIDI, the tempo determined by MIDI Clock).
071: Stereo Pitch Shifter BPM
This stereo pitch shifter enables you to set the delay
time to match the song tempo.
BPM
BPM Base Note x Times
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Input Level
Input Level
+
High Damp
Delay
Feedback
Pitch Shifter
Feedback Position
Pre Post
Tempo
Tempo
BPM
BPM Base Note x Times
Base Note x Times
Left
Right
Feedback Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
High Damp
High Damp
Input Level
Input Level
Feedback Position
Pre
Pre
Post
Post
Delay Pitch Shifter
Delay Pitch Shifter
