Delay 091: L/C/R BPM Delay
841
091: L/C/R BPM Delay
The L/C/R delay enables you to match the delay time
with the song tempo. You can also synchronize the
delay time with the arpeggiator or sequencer. If you
program the tempo before performance, you can
achieve a delay effect that synchronizes with the song
in real-time. Delay time is set by notes.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
DELAY
BPM [MIDI, 40.00…240.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect. p.822.
Time Over?>. [---, OVER!]
The maximum delay time is 2,730msec. If the
combination of BPM, Base Note, and Times exceeds
this limit, the error message “OVER!” appears in the
display. If this occurs, change the delay time
parameters so that this message no longer appears.
L Delay Base Note [ … ]
Selects the type of notes to specify the delay time for
the Left Delay. p.822.
Times [x1…x32]
Sets the number of notes to specify the delay time for
the Left Delay. p.822.
Level [0…50]
Sets the output level of the Left Delay.
C Delay Base Note [ … ]
Selects the type of notes to specify the delay time for
the Center Delay. p.822
Times [x1…x32]
Sets the number of notes to specify the delay time for
the Center Delay. p.822.
Level [0…50]
Sets the output level of the Center Delay.
R Delay Base Note [ … ]
Selects the type of notes to specify the delay time for
the Right Delay. p.822
Times [x1…x32]
Sets the number of notes to specify the delay time for
the Right Delay. p.822.
Level [0…50]
Sets the output level of the Right Delay.
Feedback (C Delay) [+/–100]
Sets the feedback amount of the Center Delay.
Source [Off…Tempo]
Selects the modulation source for the Center Delay
feedback.
Amount [+/–100]
Sets the modulation amount of the Center Delay
feedback.
High Damp [%] [0…100]
Sets the damping amount in the high range. p.829.
Low Damp [%] [0…100]
Sets the damping amount in the low range. p.829.
Spread [0…50]
Sets the width of the stereo image of the effect sound.
p.829.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
C Delay
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
Input Level D-mod
High Damp Low Damp
L Delay Input Level D-mod
+
Level
Level
Level
Tempo
BPM
BPM Base Note x Times
Base Note x Times
Base Note x Times
R Delay
