Effect Guide
834
When Polarity is positive, the “Target” value is
obtained by multiplying the parameter value by the
“Offset” value (if the input level is below the
threshold), or equals the parameter value if the input
level exceeds the threshold.
When Polarity is negative, Control Target value equals
the parameter value if the input level is below the
threshold, or is obtained by multiplying the parameter
value by the “Offset” value if the level exceeds the
threshold.
CONTROL: Attack and Release
The “Attack” and “Release” parameters specify attack
time and release time of delay level control
084: Stereo Auto Panning Delay
This stereo delay effect pans the delay sound left and
right using the LFO.
DELAY
L Delay Time [msec] [0.0…1360.0]
Sets the delay time for the left channel.
R Delay Time [msec] [0.0…1360.0]
Sets the delay time for the right channel.
L Feedback [+/–100]
Sets the feedback amount for the left channel.
R Feedback [+/–100]
Sets the feedback amount for the right channel.
High Damp [%] [0…100]
Sets the damping amount in the high range. p.829.
Low Damp [%] [0…100]
Sets the damping amount in the low range. p.829.
LFO
Waveform [Triangle, Sine]
Selects the LFO Waveform.
Shape [+/–100]
Changes the curvature of the LFO Waveform. p.780.
Phase [degrees] [–180…+180]
Sets the LFO phase difference between the left and
right. p.814.
Frequency [Hz] [0.02…20.00]
This sets the LFO speed, in Hz. It applies only when
MIDI/Tempo Sync, below, is Off.
MIDI/Tempo Sync [Check-box]
BPM [MIDI, 40.00…240.00]
Base Note [ … ]
Times [x1…x32]
When MIDI/Tempo Sync is on, the LFO speed is set by
BPM, Base Note, and Times, instead of Frequency. For
more information, see “MIDI/Tempo Sync” on
page 777.
Type [Individual, Common1, Common2]
This controls whether the effect uses its individual
LFO, or one of the Common FX LFOs. For more
information, see “LFO Type” on page 777.
Common LFO Phase Offset [degrees] [+/–180]
When Type is set to Common FX LFO 1 or 2, this lets
you offset the phase from the master LFO.
AUTO PAN
Depth [0…100]
Sets the panning width.
Source [Off…Tempo]
Selects the modulation source for the panning width.
Amount [+/–100]
Set the modulation amount of the panning width.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
Dynamic Delay
Threshold
Dry
Envelope
Wet
Target=Output Level
Polarity= (—)
Wet
Target=Output Level
Polarity= (+)
Delay Time
Time
(Ducking Delay)
Release
Attack
Level
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO Phase
LFO Shape
Pan
Pan
LFO: Tri / Sin
Depth
Delay
Delay
High Damp Low Damp
High Damp Low Damp
Feedback
