Effect Guide
764
Dynamics
000: No Effect
Choose this option when you are not using the selected
effects slot. This frees up processing resources for other
effects and/or synth voices. When a slot is set to No Effect:
• Insert Effects and Total Effects pass through the
dry, unprocessed signal
• Master Effects mute their outputs
001: Stereo Dyna Compressor
This effect compresses the input signal to regulate the
level and give a “punchy” effect. It is useful for guitar,
piano, and drum sounds. This is a true stereo effect;
you can link the left and right channels, or use each
channel separately.
ENVELOPE
Select [L/R Mix, L/R Individually]
This determines how the left and right channels of the
selected Source are used for controlling the
compressor. Note that this applies only to the control
signal; the effect always processes both channels of the
input signal in stereo.
L/R Mix is generally the best choice for stereo signals;
this compresses both channels equally, based on the
combined volumes of the left and right channels.
L/R Individually splits the effect into two separately
controlled mono compressors. When processing stereo
signals, this will cause the stereo image to shift.
Pre EQ
Trim [0…100]
This sets the input level for the EQ.
LEQ Fc [Low, Mid-Low]
Selects the frequency of the EQ’s low band.
LEQ Gain [dB] [–15.0…+15.0]
Sets the gain of the Low EQ.
HEQ Fc [High, Mid-High]
Selects the frequency of the EQ’s high band.
HEQ Gain [dB] [–15.0…+15.0]
Sets the gain of the High EQ.
COMPRESSOR
Sensitivity [1…100]
This controls the amount of compression. Increasing
the value boosts lower level sounds, and raises the
overall volume.
To adjust the final volume, use the Output Level
parameter.
Attack [1…100]
This controls the onset time of the compressor.
Output Level [0…100]
Sets the output level of the compressor.
Source [Off…Tempo]
Selects the modulation source for the Output Level.
Amount [+/–100]
Sets the modulation amount for the Output Level.
OUTPUT
Wet/Dry [Dry, 1:99…99:1, Wet]
Sets the balance between the “wet” processed sound
and the dry input.
Source [Off…Tempo]
Selects a modulation source for Wet/Dry.
Amount [+/–100]
Sets the modulation amount for Wet/Dry.
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
EQ Trim
EQ Trim
LEQ HEQ
LEQ HEQ
Compressor
Compressor
Envelope Select
Output Level
Output Level
Envelope - Control
Envelope - Control
Sensitivity=100
Sensitivity=40
Dry
Wet
Time
Level
Dyna Compressor - Sensitivity
Louder
Dry
Wet
Time
Level
Attack=80
Attack=20
Dyna Compressor - Attack
