EXi: STR-1 Plucked String
278
STR-1 Tone Adjust
STR-1 Tone Adjust Default Settings
Tone Adjust provides an elegant physical interface to
the STR-1’s parameters. Most of the factory sounds use
the default layout, as shown above. You can also
customize the layout for individual sounds, if desired.
For more information about Tone Adjust, please see
“0–9f: Tone Adjust,” on page 26.
STR-1 Tone Adjust parameters
The STR-1 supports all of the Common Tone Adjust
parameters, as described under “0–9f: Tone Adjust,” on
page 26. It also adds a number of its own additional
parameters, which apply only to the STR-1.
Note that these additional parameters are separate for
each EXi, as opposed to being shared by both EXi in
the Program.
All of the additional parameters are listed below. Tone
Adjust parameters may affect the internal parameters
in one of two ways: they may be Relative, in which
case they scale the existing parameter value, or
Absolute, in which case they over-write the existing
value. Unless otherwise noted, all of the STR-1
parameters are Absolute.
The full name of the currently selected parameter is
shown in the status line at the top of the Control
Surface page, as well as in the popup menu. Some
parameters with longer names may show an
abbreviation for the slider, knob, and switch labels.
Pluck
• Pluck Type
• Pluck Randomization
• Pluck Delay
• Pluck Width
• Pluck Width AMS1 Intensity
Noise
• Noise Saturation
• Noise Filter Frequency
PCM Oscillator
• PCM Osc MS Select (PROG/0…16383)
• PCM Osc MS Bank (MS: ROM Mono…EXs7 Mono)
• PCM Osc MS Min # (meta)
• PCM Osc MS Max # (meta)
• PCM Osc Start Offset
• PCM Osc Reverse
PCM Pitch
• PCM Tune (–1200...+1200, relative)
• PCM Transpose (–12...+12, relative)
• PCM Pitch Slope
• PCM Pitch LFO AMS Intensity
Excitation Mixer
• Excitation PCM Oscillator level
• Excitation Pluck Level
• Excitation Noise Level
Damping Damping
Switches 1 & 2:
PCM Transpose +12,
String Transpose +12 Switches 1 & 2:
PCM Transpose +12,
String Transpose +12
Harmonic
Position
Harmonic
Position
Excitation
Position
Excitation
Position
Pickup 1
Position
Pickup 1
Position
Pickup 2
Position
Pickup 2
Position Dispersion Dispersion Decay Decay Nonlinearity Nonlinearity
Pluck Type Pluck Type Pickup 1
Level
Pickup 1
Level
Pickup 2
Level
Pickup 2
Level
String Level String Level PCM Osc
Level
PCM Osc
Level
Noise
Level
Noise
Level
Pluck Randomization Pluck Randomization Pluck Width Pluck Width
Harmonic Pressure
AMS Intensity
Harmonic Pressure
AMS Intensity
Switches 7, 8, 15, 16:
LFOs 1, 2, 3, 4 Stop Switches 7, 8, 15, 16:
LFOs 1, 2, 3, 4 Stop
