Delay 080: Stereo/Cross Long Delay
831
080: Stereo/Cross Long Delay
This is a stereo delay, and can by used as a cross-
feedback delay effect in which the delay sounds cross
over between left and right by changing the feedback
routing. You can set a maximum of 2,730msec for the
delay time.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
DELAY
Stereo/Cross [Stereo, Cross]
Switches between stereo delay and cross-feedback
delay.
L Delay Time [msec] [0.0…] 2730.0
Sets the delay time for the left channel.
R Delay Time [msec] [0.0…] 2730.0
Sets the delay time for the right channel.
L Feedback [+/–100]
Sets the feedback amount for the left channel.
R Feedback [+/–100]
Sets the feedback amount for the right channel.
Source [Off…Tempo]
Selects the modulation source of feedback amount.
L Amount [+/–100]
Sets the modulation amount of the left channel
feedback.
R Amount [+/–100]
Sets the modulation amount of the right channel
feedback.
High Damp [%] [0…100]
Sets the damping amount in the high range. p.829.
Low Damp [%] [0…100]
Sets the damping amount in the low range. p.829.
Spread [–50…+50]
Sets the width of the stereo image of the effect sound.
p.829.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
081: Stereo Multitap Delay
The left and right Multitap Delays have two taps
respectively. Changing the routing of feedback and tap
output allows you to create various patterns of
complex effect sounds.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level ✎ p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
DELAY
Mode [Normal, Cross Feedback,
Cross Pan1, Cross Pan2]
This lets you alter the stereo image by switching the
inputs and feedback paths of the left and right delays,
as shown in the figure below. In order for this to be
effective, the input needs to be a true stereo signal.
Tap1 Time [msec] [0.0…1360.0]
Sets the Tap1 delay time.
Delay
Delay
Stereo/Cross
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp Low Damp
Spread Stereo/Cross
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp Low Damp
Delay
Delay
Feedback
Tap1 Level Mode Mode
(1)
(2)
(1)
(2)
Tap1=(1)
Tap2=(2)
Mode: Normal Mode: Cross Feedback
Mode: Cross Pan1 Mode: Cross Pan2
