Effect Guide
804
OUTPUT
Wet/Dry [–Wet…–1:99, Dry, 1: 99…Wet]
Sets the balance between the “wet” processed sound
and the dry input. Negative values invert the phase of
the wet signal. This interacts with Feedback; for more
information, see “Feedback” on page 803.
Source [Off…Tempo]
Selects a modulation source for Wet/Dry.
Amount [+/–100]
Sets the modulation amount for Wet/Dry.
049: Stereo Random Flanger
The stereo effect uses a step-shape waveform and
random LFO for modulation, creating a unique
flanging effect.
FLANGER
Delay Time [msec] [0.0…50.0]
Sets the delay time from the original sound.
Depth [0…100]
Sets the depth of LFO modulation.
Feedback [+/–100]
This controls the intensity of the flanger. For more
information, see “Feedback” on page 803.
High Damp [%] [0…100]
Sets the feedback damping amount in the high range.
p.803.
LFO
These parameters control the shape and speed of the
step LFO. They are identical to those in the Stereo
Random Filter; for more information, see “LFO” on
page 779.
O UTPUT
Wet/Dry [–Wet…–1:99, Dry, 1: 99…Wet]
Sets the balance between the “wet” processed sound
and the dry input. Negative values invert the phase of
the wet signal. This interacts with Feedback; for more
information, see “Feedback” on page 803.
Source [Off…Tempo]
Selects a modulation source for Wet/Dry.
Amount [+/–100]
Sets the modulation amount for Wet/Dry.
050: Stereo Envelope Flanger
This Flanger uses a MIDI-triggerable envelope
generator for modulation. This lets you create
sequences with flanger sweeps which always happen
on the same beat, for instance. You can also control the
Flanger directly using a modulation source.
CONTROL
Sweep Mode [EG, Dmod]
When Sweep Mode is set to EG, the envelope
generator controls the flanger. Note that this is the
effect’s own EG, and isn’t related to the Program’s
other EGs (Filter, Amp, etc.).
The Source parameter, below, selects the source that
starts the envelope generator. If you select Gate, for
example, the envelope will be triggered by note-ons.
The EG is triggered when the MIDI source’s value
changes from 63 or smaller to 64 or higher.
When Sweep Mode is set to Dmod, the modulation
source directly controls the flanger. Select the
modulation source using the Source parameter, below.
Source [Off…Tempo]
Selects the modulation source that triggers the EG
(when Sweep Mode = EG), or the modulation source
that causes the flanger to sweep (when Sweep Mode =
Dmod).
EG
Attack [1…100]
Sets the EG attack time. For more information Attack
and Release, see the graphic under “Attack [msec]” on
page 766.
LFO: Step-Tri/Random
Left
Right
Feedback
LFO Phase
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
Flanger
Flanger
EG Attack/Decay
EG
D-mod
Sweep Mode
D -mod
Flanger
Flanger
Left
Right
Feedback
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
