Modulation and Pitch Shift 069: Stereo Pitch Shifter
821
High Damp [%] [0…100]
Sets the damping amount in the high range.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
PITCH SHIFTER: Mode
This parameter switches the pitch shifter operating
mode. With Slow, tonal quality will not be changed too
much. With Fast, the effect becomes a Pitch Shifter that
has a quick response, but may change the tone.
Medium is in-between these two. If you do not need to
set too much pitch shift amount, set this parameter to
Slow. If you wish to change the pitch significantly, use
Fast.
PITCH SHIFTER: Fine Amount, Fine [cents], Pitch Shift
Amount, Source, Pitch Shift [semitone]
The amount of pitch shift will use the value of the
Pitch Shift plus the Fine value. The amount of
modulation will use the Amount value plus Fine
Amount.
The same Modulation Source is used for both Pitch
Shift and Fine.
DELAY: Feedback and Feedback Position
When Feedback Position is set to Pre, the pitch shifter
output is again input to the pitch shifter. Therefore, if
you specify a higher value for the Feedback parameter,
the pitch will be raised (or lowered) more and more
each time feedback is repeated.
If Feedback Position is set to Post, the feedback signal
will not pass through the pitch shifter again. Even if
you specify a higher value for the Feedback parameter,
the pitch-shifted sound will be repeated at the same
pitch.
069: Stereo Pitch Shifter
This is a stereo pitch shifter. The pitch shift amount for
the left and right channels can be reversed from each
other.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
PITCH SHIFTER
Mode [Slow, Medium, Fast]
Switches Pitch Shifter mode. p.821.
L/R Pitch [Normal, Up/Down]
Determines whether or not the L/R pitch shift amount
is inverted.
Normal: The pitches of the left and right channels shift
together.
Up/Down: the pitch shift amount for the right channel
will be reversed. If the pitch shift amount is positive,
the pitch of the left channel is raised, and the pitch of
the right channel is lowered.
Pitch Shift [1/2 steps] [–24…+24]
Sets the pitch shift amount in steps of a semitone.
p.821.
Fine [cents] [+/–100]
Sets the pitch shift amount in steps of one cent. p.821
Source [Off…Tempo]
Selects the modulation source of pitch shift amount.
p.821.
Pitch Shift Amount [–24…+24]
Sets the modulation amount of pitch shift amount.
p.821.
Fine Amount [+/–100]
Sets the modulation amount of pitch shift amount.
p.821.
DELAY
L Delay Time [msec] [0…2000]
Sets the delay time for the left channel.
R Delay Time [msec] [0…2000]
Sets the delay time for the right channel.
Feedback Position [Pre, Post]
Switches the feedback connection. p.821.
Feedback [+/–100]
Sets the feedback amount. p.821.
High Damp [%] [0…100]
Sets the damping amount in the high range.
Spread [+/–100]
Sets the width of the stereo image of the effect sound.
p.829.
Left
Right
Feedback Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
High Damp
High Damp
Input Level
Input Level
Feedback Position
Pre
Pre
Post
Post
Delay Pitch Shifter
Delay Pitch Shifter
