3-18 Signal Description
Version 2.2 Copyright © 2001, 2002, 2003 by LSI Logic Corporation. All rights reserved.
Table 3.17 lists the LSI Logic test signals.
Table 3.17 LSI Logic Test Pins
Signal Name BGA Position Type Strength Description
SCANEN N22 I N/A SCANEN is for use only by LSI Logic.
SCANMODE E7 I N/A SCANMODE is for use only by LSI Logic.
IDDTN Y4 I N/A IDDTN is for use only by LSI Logic.
CLKMODE_0 AA22 I N/A CLKMODE_0 is for use only by LSI Logic.
CLKMODE_1 AC2 I N/A CLKMODE_1 is for use only by LSI Logic.
DIS_PCI_FSN/ A24 I N/A Pulling DIS_PCI_FSN/ LOW disables the PCI
FSN. Pulling this pin HIGH allows the chip to
enable the PCI FSN when operating in PCI-X
mode, or to disable the PCI FSN when
operating in PCI mode. The LSI53C1030
controls the PCI FSN.
DIS_SCSI_FSN/ AC4 I N/A DIS_SCSI_FSN/ is for use only by LSI Logic.
TESTACLK AB6 I N/A TESTACLK is for use only by LSI Logic.
TESTHCLK AE2 I N/A TESTHCLK is for use only by LSI Logic.
TN C5 I N/A TN is for use only by LSI Logic.
TESTCLKEN D7 I N/A TESTCLKEN is for use only by LSI Logic.
