PCI Bus Interface Signals
3-5
Version 2.2
Copyright © 2001, 2002, 2003 by LSI Logic Corporation. All rights reserved.
3.2.2 PCI Address and Data Signals
describes the PCI Address and Data signals group.
Table 3.2
PCI Address and Data Signals
Signal Name
BGA Position
Type
Strength Description
AD[63:0]
W22, AB25, AC26,
AA25, W23, Y25, Y26,
V22, U22, V24, V23,
U24, V25, W26, U23,
U25, T22, T23, T25,
R25, R22, P22, P23,
R23, P24, P25, T26,
R26, M26, L26, N25,
N24, AE9, AF8, AE10,
AB11, AC11, AE11,
AE12, AB12, AC12,
AD13, AE13, AF11,
AF16, AE14, AC15,
AC14, AD17, AE19,
AC18, AB17, AB18,
AF20, AE20, AC19,
AF23, AE22, AB19,
AD21, AF24, AC20,
AE23, AC21
I/O
8 mA
PCI
Refer to the PCI Local Bus
Specification, Version 2.2, and the
PCI-X Addendum to the PCI Local
Bus Specification, Version 1.0a, for
this signal description.
C_BE[7:0]/
AA23, AC25, Y23,
AD26, AB13, AB14,
AE18, AE21
I/O
8 mA
PCI
Refer to the PCI Local Bus
Specification, Version 2.2, and the
PCI-X Addendum to the PCI Local
Bus Specification, Version 1.0a, for
this signal description.
PAR
AF19
I/O
8 mA
PCI
Refer to the PCI Local Bus
Specification, Version 2.2, and the
PCI-X Addendum to the PCI Local
Bus Specification, Version 1.0a, for
this signal description.
PAR64
AA24
I/O
8 mA
PCI
Refer to the PCI Local Bus
Specification, Version 2.2, and the
PCI-X Addendum to the PCI Local
Bus Specification, Version 1.0a, for
this signal description.
