3.2.6 PCI Interrupt Signals
describes the PCI Interrupt signals group.
Table 3.6
PCI Interrupt Signals
Signal Name
BGA Position
Type
Strength Description
INTA/
AC8
O
8 mA
PCI
Refer to the PCI Local Bus Specification,
Version 2.2, and the PCI-X Addendum to the
PCI Local Bus Specification, Version 1.0a, for
this signal description.
The LSI53C1030 can route interrupts to INTA/
and/or ALT_INTA/. The interrupt request
routing mode bits, bits [9:8] in the PCI
register, control the routing of
interrupt signals to INTA/ and/or ALT_INTA/.
INTB/
AE7
O
8 mA
PCI
Refer to the PCI Local Bus Specification,
Version 2.2, and the PCI-X Addendum to the
PCI Local Bus Specification, Version 1.0a, for
this signal description.
The LSI53C1030 can route interrupts to
INTB/ and/or ALT_INTB/. The interrupt
request routing mode bits, bits [9:8] in the PCI
register, control the
routing of interrupt signals to INTB/ and/or
ALT_INTB/.
