Package Drawings 5-21
Version 2.2 Copyright © 2001, 2002, 2003 by LSI Logic Corporation. All rights reserved.
Figure 5.12 LSI53C1030 456-Pin BGA Top View (Cont.)
A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24 A25 A26
VDD_IO B_SBSY − B_SRST+ VSS_IO VDD_IO B_SD8 − B_SD9+ VSS_IO VDD_IO B_SD11+
DIS_PCI_
FSN/ VSS_IO VDD_IO
B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24 B25 B26
B_SATN − B_SBSY+ B_SMSG − B_SSEL − B_SREQ − B_SD8+ B_SD10+ B_SD11 −
B_
DIFFSENS ADV/ MADP0 MAD13 VSS_IO
C14 C15 C16 C17 C18 C19 C20 C21 C22 C23 C24 C25 C26
VSSC VDD_IO VSS_IO B_SSEL+ B_SREQ+ VDD_IO VSS_IO VSSC MADP1 VDD_IO MAD10 HB_LED/ VSSC
D14 D15 D16 D17 D18 D19 D20 D21 D22 D23 D24 D25 D26
B_SACK − VDDC B_SMSG+ B_SCD+ B_SIO+ B_SD10 − RAMCE/ ADSC/ MAD15 MAD12 VSS_IO MAD2 MAD7
E14 E15 E16 E17 E18 E19 E20 E21 E22 E23 E24 E25 E26
B_SACK+ B_SRST − B_SCD − B_SIO − B_SD9 − VDDC MCLK MAD14 MAD11 MAD8 BWE1/ MAD6 VDD_IO
F22 F23 F24 F25 F26
MAD9 MAD1 MAD4 VSSC VSS_IO
G22 G23 G24 G25 G26
MAD0 MAD3 VDD_IO FLSHCE/ MOE/
H22 H23 H24 H25 H26
MAD5 BWE0/ VSS_IO GPIO3 SerialDATA
J22 J23 J24 J25 J26
VDDC A_LED/ FLSHALE1/ SerialCLK VDD_IO
K22 K23 K24 K25 K26
FLSHALE0/ B_LED/ GPIO2 GPIO7 VSS_IO
L14 L15 L16 L22 L23 L24 L25 L26
VSS_IO VSS_IO VSS_IO VSSC GPIO6 VDD_IO GPIO5 AD34
M14 M15 M16 M22 M23 M24 M25 M26
VSS_IO VSS_IO VSS_IO VDDC PCI5VBIAS VSS_IO GPIO4 AD35
N14 N15 N16 N22 N23 N24 N25 N26
VSS_IO VSS_IO VSS_IO SCANEN ZCR_EN/ AD32 AD33 VDD_IO
P14 P15 P16 P22 P23 P24 P25 P26
VSS_IO VSS_IO VSS_IO AD42 AD41 AD39 AD38 VSS_IO
R14 R15 R16 R22 R23 R24 R25 R26
VSS_IO VSS_IO VSS_IO AD43 AD40 VDD_IO AD44 AD36
T14 T15 T16 T22 T23 T24 T25 T26
VSS_IO VSS_IO VSS_IO AD47 AD46 VSS_IO AD45 AD37
U22 U23 U24 U25 U26
AD55 AD49 AD52 AD48 VDD_IO
V22 V23 V24 V25 V26
AD56 AD53 AD54 AD51 VSS_IO
W22 W23 W24 W25 W26
AD63 AD59 VDD_IO PCI5VBIAS AD50
Y22 Y23 Y24 Y25 Y26
PCI5VBIAS C_BE5/ VSS_IO AD58 AD57
AA22 AA23 AA24 AA25 AA26
CLK
MODE_0 C_BE7/ PAR64 AD60 VDD_IO
AB14 AB15 AB16 AB17 AB18 AB19 AB20 AB21 AB22 AB23 AB24 AB25 AB26
C_BE2/ FRAME/ STOP/ AD12 AD11 AD5 ACK64/ VDDA PCI5VBIAS VSSC VSSC AD62 VSS_IO
AC14 AC15 AC16 AC17 AC18 AC19 AC20 AC21 AC22 AC23 AC24 AC25 AC26
AD16 AD17 DEVSEL/ SERR/ AD13 AD8 AD2 AD0 CLK GPIO0 VDD_IO C_BE6/ AD61
AD14 AD15 AD16 AD17 AD18 AD19 AD20 AD21 AD22 AD23 AD24 AD25 AD26
VSSC VSS_IO VDD_IO AD15 PCI5VBIAS VSS_IO VDD_IO AD4 REQ64/ VSS_IO VSSA VDDC C_BE4/
AE14 AE15 AE16 AE17 AE18 AE19 AE20 AE21 AE22 AE23 AE24 AE25 AE26
AD18 IRDY/ TRDY/ PERR/ C_BE1/ AD14 AD9 C_BE0/ AD6 AD1 VDDC GPIO1 VDD_IO
AF14 AF15 AF16 AF17 AF18 AF19 AF20 AF21 AF22 AF23 AF24 AF25 AF26
VSS_IO VDDC AD19 VDD_IO VSS_IO PAR AD10 VDD_IO VSS_IO AD7 AD3 VDD_IO VSS_IO
