PCI Configuration Space Register Description 4-15
Version 2.2 Copyright © 2001, 2002, 2003 by LSI Logic Corporation. All rights reserved.
Capabilities Pointer [7:0]
This register indicates the location of the first extended
capabilities register in PCI Configuration Space. The
value of this register varies according to system configu-
ration.
Register: 0x35–0x37
Reserved
Reserved [23:0]
This register is reserved.
Register: 0x38–0x3B
Reserved
Reserved [31:0]
This register is reserved.
Register: 0x3C
Interrupt Line
Read/Write
Interrupt Line [7:0]
This register communicates interrupt line routing informa-
tion. Power-On-Self-Test (POST) software writes the rout-
ing information into this register as it configures the
system. This register indicates the system interrupt con-
troller input to which this PCI function’s interrupt pin con-
nects. System architecture determines the values in this
register.
23 0
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
31 0
Reserved
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
7 0
Interrupt Line
0 0 0 0 0 0 0 0
