Page 152
In this chapter
˽ Physical Features
˽ Installation
14
Click 201/202/204 modules are 120–240 VAC to 24 VDC power supplies. One of these
modules should be used as part of the power plant, providing reliable DC power to the rest
of the cabinet, unless a Click 203 is used (see Chapter 1).
A Click 201 provides 1 A of power and is capable of powering a single Wavetronix Smart-
Sensor; a Click 202 provides 2 A and can power two sensors; and a Click 204 provides 4 A
and can power four sensors.
Figure 14.1 – The Click 201, 202 and 204
Click 201/202/204 —
AC to DC Power Supply
14
