I CHANNEL
--▓------
I channel activity fault. Indicates a loss of
activity in the I channel of the quadrature
demodulator
Q CHANNEL
---▓-----
Q channel activity fault. Indicates a loss of
activity in the Q channel of the quadrature
demodulator
BER THRESHOLD
----▓----
Secondary alarm result of the BER threshold
set in the DEMOD Configuration menu
MODULE
-----▓---
Demodulator/decoder module fault
CONFIGURATION
------▓--
Demodulator/decoder configuration fault
LNB
-------▓-
LNB configuration fault
4.2.1.1.3.3 Faults/Alarms – Tx Interface
DISPLAY SELECTIONS/DESCRIPTION
TX INTERFACE
-------
Note: “-” indicates status of parameter is OK.
“+” indicates a fault.
Reverse contrast “+” indicates an
alarm.
TX CLK PLL
--▓----
Transmitter phase-locked loop fault. Indicates
the transmitter Phase-Locked Loop (PLL) is
not locked
CONFIGURATION
------▓
TX interface configuration fault.
Indicates the TX interface cannot execute a
programmed configuration parameter
