CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
40
2.3.1 E
THERNET
I
NTERFACE
C
ONNECTOR
The 10/100 BaseT Ethernet connector is a RJ45-8 modular jack located on the rear panel.
This interface is used for data traffic and M & C. This interface is a Network Interface
Card (NIC) pinout.
Table 12. Ethernet Interface Connector
Pin Function
1 Tx+
2 Tx-
3 Rx+
4 N/C
5 N/C
6 Rx-
7 N/C
8 N/C
2.3.1 A
SYNC
-S
ERIAL
C
ONSOLE
The Console Connector is a RJ11-6 modular jack located on the rear panel. The Async-
Serial Console interfaces the IP Module Command Line Interface (CLI). This interface is
a RS-232 DCE interface.
Table 13. ASYNC-Serial Console Connector
Pin Function
1 Ground
2 Rx
3 Tx
4 Ground
5 No used
6 Not used
