CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
249
OID Description
cdmip300LTxCarrierState Transmit carrier on/off state. Can be set to:
0 Off
1 On
2 Ext Off
3 Rti
8.6.1.3 R
X
P
ARAMETERS
Table 56. Rx Parameters OIDs
OID Description
cdmip300LRxFrequency Receive frequency in Hz. Can be set from 52,000,000
Hz to 88,000,000 Hz and 104,000,000 Hz to
188,000,000 Hz.
cdmip300LRxDataRate Receive data rate in bps. Can be set between 2,400 bps
and 2,048,000 bps.
cdmip300LRxDemodType Receive demodulation type. Can be set to:
1 BPSK
2 QPSK
3 OQPSK
cdmip300LRxFECType Receive forward error correction decoding type. Can be
set to:
0 None
1 Vit
2 Turbo Q 3/4
3 Turbo B 21/44
4 Turbo B 5/16
5 Turbo OQ 3/4
6 Turbo Q 1/2
cdmip300LRxFECCodeRate Receive forward error correction code rate. Can be set
to:
1 Rate 1/2
3 Rate 3/4
7 Rate 7/8
8 Rate 21/44
9 Rate 5/16
