CDM-IP 300L IP-Centric Satellite Modem
Rev. 1
CD/CDMIP300L.IOM
159
Maximum bandwidth in kbps <0 -
99999, enter = 99999
0 -
99999
Enter desired Maximum Bandwidth in kbps.
If no Maximum is desired, select enter, Bandwidth will be
displayed as ‘99999’
Source IP address
x.x.x.x Enter desired Source IP Address or subnet.
If no Source IP is desired, select enter, Source IP will be
displayed as ‘***’
Number of source subnet bits <0,8-
32, enter = 0>:
0,8-32 Enter desired Source subnet bits.
If no Source subnet is desired, select enter, Source subnet
will be displayed as ‘/*’
Destination IP address
x.x.x.x Enter desired Destination IP Address or subnet.
If no Destination IP is desired, select enter, Destination IP
will be displayed as ‘***’
Number of Destination subnet bits
<0,8-32, enter = 0>:
0,8-32 Enter desired Destination subnet bits.
If no Destination subnet is desired, select enter, Destination
subnet will be displayed as ‘/*’
Specify TCP/UDP source port [MIN]
(1 - 65535)
1 -
65535
Enter desired TCP/UDP source port (or Min port of a range).
If no TCP/UDP source port is desired, select enter, Source
port will be displayed as ‘***’
Specify TCP/UDP source port [MAX]
(1 - 65535)
1 -
65535
Enter desired TCP/UDP source port (or Max port of a
range).
Will not display if no MIN TCP/UDP source port was
selected.
Specify TCP/UDP destination port
[MIN] (1 - 65535)
1 -
65535
Enter desired TCP/UDP destination port (or Min port of a
range).
If no TCP/UDP destination port is desired, select enter,
Destination port will be displayed as ‘***’.
Specify TCP/UDP destination port [MAX]
(1 - 65535)
1 -
65535
Enter desired TCP/UDP destination port (or Max port of a range).
Will not display if no MIN TCP/UDP destination port was selected.
Set WRED (Weighted Random Early
Discard)
Y or N
Select to enable Weighted Random Early Detect.
Specify Filtering for the rule
Y or N
Select to prevent traffic defined in rule to be forwarded.
Default N = not filtered
Delete
D
Enter the QoS Rule to delete <1..32>
Base [1]
B
Select Base to view, edit, or display a different set of 8 QoS Rules.
For example, if 8 QoS Rules have been defined, add a new rule by
selecting B 9. The QoS Configuration page will refresh and now
display QoS Rules 9 – 16.
QoS [ ]
Read
Only
Displays state of QoS option – Unavailable, Enabled Disabled. If
available, QoS is Enabled or Disabled from the Administrator
Features Page.
Save Parameters
S
This option allows a user to save the current configuration of the
CDM-IP to permanent storage. This configuration will be restored
on each successive power cycle of the CDM-IP.
Exit
X
This option allows a user to exit the current menu and return to its
parent menu.
