4.2.1.1.2.3 Monitor – Eb/No
DISPLAY SELECTIONS/DESCRIPTION
EB/NO
No Data
Displays the current Eb/No or “No Data” (if
carrier is not locked).
Range: 2.0 to 16.0 dB.
Note: Low limit is based on the data rate.
High limit is 16.0 dB.
4.2.1.1.2.4 Monitor – Receive Signal
DISPLAY SELECTIONS/DESCRIPTION
RECEIVE SIGNAL
<91.9dBm
Displays the current receive signal level.
Range: -25.0 to –91.9 dBm.
4.2.1.1.2.5 Monitor – Sweep Frequency
DISPLAY SELECTIONS/DESCRIPTION
SWEEP FREQUENCY
No Data
Displays the current offset frequency or “No
Data” if carrier is not locked
Range: -35,000 to +35,000 Hz
4.2.1.1.2.6 Monitor – Buffer Fill
DISPLAY SELECTIONS/DESCRIPTION
BUFFER FILL
50%
Displays the current plesiochronous buffer fill
status percent.
Range: 1 to 99%.
4.2.1.1.2.7 Monitor – LNB Current
DISPLAY SELECTIONS/DESCRIPTION
LNB CURRENT
Monitors the LNB current or LNB POWER OFF.
Current displayed is 0 to 500 mA in 1 mA
increments
