CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
250
OID Description
cdmip300LRxSpecInv Receive spectrum inversion state. Can be set to:
0 Normal
1 Inverted
cdmip300LRxDescrambler Receive descrambler state. Can be set to:
0 Off
1 On
cdmip300LRxClockMode Receive clock mode. Can be set to:
0 Disabled
1 Enabled
cdmip300LRxBufferSize Receive buffer size in bits. Can be set to:
1 256 bits
2 512 bits
3 1024 bits
4 2048 bits
5 4096 bits
cdmip300LRxAcqSweepRange Receive +/- acquisition sweep range of demodulation in
KHz. Can be set between 1 and 30.
cdmip300LRxEbnoAlarmPoint Receive E
b
/N
0
alarm point in dB. Can be set between 0
and 160 in 0.1 dB where (0=0.0 dB to 160=16.0 dB).
8.6.1.4 I
NTERFACE
P
ARAMETERS
Table 57. Interface Parameters OIDs
OID Description
cdmip300LIfImpedance IF interface impedance. Can be set to:
5 50 Ω
7 75 Ω
cdmip300LInterfaceType Unit interface type. Can only be set to IP.
4 IP
