Fault connector and pinouts (j7), Table 15. fault connector and pinouts (j7) – Comtech EF Data CDM-IP 300L User Manual
Page 69

CDM-IP 300L IP-Centric Satellite Modem
Rev. 1
CD/CDMIP300L.IOM
42
2.3.5 F
AULT
C
ONNECTOR AND
P
INOUTS
(J7)
The fault connector provides Form C contact closures for fault reporting. The three Form C
summary fault contacts, ratings 1 A maximum at 24 Vdc, 0.5 A at 120 Vac, are Modulator,
Demodulator, and Common Equipment.
The fault interface connection is a 9-pin subminiature female D connector (J7) located on
the rear panel of the modem. Screw locks are provided for mechanical security on the
mating connector.
Table 15. Fault Connector and Pinouts (J7)
Pin #
Signal Function
Name
1
Common equipment is not faulted
NO
2
COM
3
Common equipment is faulted
NC
4
Modulator is not faulted
NO
5
COM
6
Modulator is faulted
NC
7
Demodulator is not faulted
NO
8
COM
9 Demodulator
is
faulted
NC
Note:
A connection between the common (COM) and normally open (NO) contacts
indicates no fault.
