Comtech EF Data CDM-IP 300L - Manual (Page 273)

CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
247
8.6 CDM-IP300L P
RIVATE
MIB
IMPORTANT
Whenever modifying the Modulator or Demodulator parameters by SNMP, the
user must be aware that the following variables must be executed in this order:
1. FEC (Forward Error Correction)
2. Modulation or Demodulation
3. Code Rate
4. Data Rate
8.6.1 CDM-IP300L O
BJECTS
G
ROUP
8.6.1.1 S
YSTEM
I
NFORMATION
:
Table 54. ARP Configuration Subgroup OIDs
OID Description
cdmip300LEquipmentID Unit’s equipment ID.
cdmip300LUnitSerialNumber Unit’s serial number.
cdmip300LSoftwareRevision Unit’s software revision.
cdmip300LDeviceTime Device time. Current time is in hh:mm:ss format.
cdmip300LDeviceDate Device date. Current date is in mm/dd/yy format.
cdmip300LCircuitID Circuit ID. User defined string that will be displayed on the
front panel.
cdmip300LLocalRemoteState Local/Remote state. Can be set to:
0 Local
1 Remote
8.6.1.2 T
X
P
ARAMETERS
Table 55. Tx Parameters OIDs
OID Description
cdmip300LTxFrequency Transmit frequency in Hz. Valid ranges are from 52,000,000
Hz to 88,000,000 Hz and 104,000,000 Hz to 188,000,000 Hz.
cdmip300LTxDataRate Transmit data rate in bps. Valid range is from 2,400 bps to
2,048,000 bps.
