CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
213
8.3.1 S
YSTEM
G
ROUP
This System Group provides information about the following items:
Table 21. System Group
OID Defaults Value
sysDescr CDM-IP300L IP-Centric Modem
sysObjectID 1.3.6.1.4.1.6247.5
sysContact Comtech EFData Support,
[email protected] - User Setable
sysName CDM-IP300L - User Setable
sysLocation Empty
sysServices 79
The system services provided by the CDM-IP300L in the OSI network model are:
∑2
L-1 where L is the network layer support by the CDM-IP300L.
In the CDM-IP300L, this is calculated by 2 1-1 (layer 1) + 2 2-1 (layer 2) + 2 3-1 (layer 3) +
2 4-1 (layer 4) + 2 7-1 (layer 7) = 1 + 2 + 4 + 8 + 64 = 79.
Table 22. System Services
Network Layer Description
Layer 1 Physical
Layer 2 Datalink
Layer 3 Internet
Layer 4 End-to-end
Layer 7 Applications
