CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
74
4.2.1.1.4 Function Select – Stored/Faults
DISPLAY SELECTIONS/DESCRIPTION
FUNCTION SELECT
STORED FLTS/ALMS
MODULATOR
DEMODULATOR
TX INTERFACE
RX INTERFACE
COMMON
OUTDOOR UNIT
UNAVAL SECONDS
CLEAR ??
4.2.1.1.4.1 Stored/Faults – Modulator
DISPLAY SELECTIONS/DESCRIPTION
MODULATOR 0
11/01/02
Note:
“-” indicates status of parameter is OK.
“+” indicates a fault.
Reverse contrast “+” indicates an alarm.
IF SYNTHESIZER
▓--------
Modulator IF synthesizer fault
DATA CLOCK SYN
-▓-------
Transmit clock synthesizer fault. Indicates the
internal Voltage Controlled Oscillator (VCO)
has not locked to the incoming data clock
I CHANNEL
--▓------
I channel data activity fault
Q CHANNEL
----▓----
Q channel data activity fault
AGC LEVEL
-----▓---
TX IF AGC level fault
