8.5.2.2 S
ATELLITE
I
NTERFACE
S
UBGROUP
This subgroup defines the modem’s Satellite interface.
Table 42. Satellite Interface Subgroup OIDs
OID Description
cdmipSatelliteSubnetPrefixLen Specifies the Subnet Mask length assigned to the
Satellite Interface. Valid subnet mask prefix lengths are
between 8 and 30.
8.5.2.3 R
OUTE
T
ABLE
G
ROUP
Note: In order for the CDM-IP 300L to properly pass packets over the satellite interface, the user
MUST provide the appropriate IP to HDLC address mapping in the Route table. This Route table
is Comtech EF Data’s proprietary implementation, where the user specifies a HDLC address as a
next-hop for a route destined to satellite interface.
The cdmipIpRouteTable allows a user to define how the packets that the CDM-IP 300L
receives are routed. By this table, a user can define which DES key to use for a route.
Table 43. Route Table OIDs
OID Description
cdmipIpRouteIndex
Sequential number that corresponds to the
row index in the Route table. The route index
starts at 1.
cdmipIpRouteName Name assigned by the user to reference the
route. The assigned name cannot contain any
white space and must be unique.
cdmipIpRouteDestAddress Destination IP address for the route.
cdmipIpRouteDestMaskLen Length of the network portion of the subnet
mask.
cdmipIpRouteNextHopAddress IP address where the packet will be routed for
further processing. The Next Hop IP Address
must be on the same subnet as the Ethernet.
cdmipIpRouteMulticastOptions This OID can be set to:
1 No Routing
2 Eth To Sat Routing
3 Sat To Eth Routing
4 Sat To Eth And Eth To Sat Routing
cdmipRouteState Defines destination interface of the route
toSatellite(1)
toEthernet(2)
Set this member to ‘toSatellite’ before setting
cdmipRouteHdlcAddress.
