CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
59
4.2.1.1 O
PENING
S
CREEN
DISPLAY SELECTIONS/DESCRIPTION
CDM300L CUSTOM
VER: 2.1.14
This screen is displayed whenever power is
first applied to the unit. Pressing any key will
take the user to the top-level selection screen.
FUNCTION SELECT
CONFIGURATION
CONFIGURATION, MONITOR,
FAULTS/ALARMS, STORED/FAULTS,
REMOTE AUPC*, UTILITY.
* Conditional or option dependent.
4.2.1.1.1 Function Select – Configuration
The user is presented with the following choices:
DISPLAY SELECTIONS/DESCRIPTION
CONFIGURATION
MODULATOR
MODULATOR
DEMODULATOR
INTERFACE
*LOCAL AUPC
SAVE
RECALL
* Conditional or option dependent.
4.2.1.1.1.1 Configuration – Modulator
DISPLAY SELECTIONS/DESCRIPTION
CONFIGURATION
MODULATOR
TX-V QPSK 1/2
64.000 Kbps
Filters: A, B, C, D, or V.
See filter assignments for valid rates.
TX-IF FREQUENCY
70.0000 MHz
50 to 180 MHz (in 1 Hz steps).
* non TX/RF L-Band modem only.
or
