CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
45
2.3.11 AC P
OWER
C
ONNECTOR
A standard, detachable, non-locking, 3-prong power cord (IEC plug) supplies the
Alternating Current (AC) power to the modem. Observe the following:
Input Power 55 W maximum, 40 W typical
Input Voltage 90 to 132 or 175 to 264 Vac
Unit switches ranges
automatically.
Connector Type I.E.C
Fuse Protection
1 A SLO-BLO
Line and neutral fusing
5 mm type fuses
2.3.12 G
ROUND
C
ONNECTOR
(GND)
A #10-32 stud on the rear panel of the modem is used for connecting a common chassis
ground among all equipment.
Note: The AC power connector provides the safety ground.
