CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
110
Parameter Type Protocol Description
QCH_xxx'cr'
BERT_xxx'cr'
CONF_xxx'cr'
LNB_xxx’cr’
SFLT_xx'cr''lf']
Q Channel (OK/FLT)
BER Threshold (OK/FLT)
Configuration (OK/FLT)
LNB (OK/FLT)
Number of stored faults logged (0 to 10)
Common
Equipment
Status Command:
Response:
>add/CES_'cr'
M&C_xxx'cr'
INT_xxx'cr'
BAT_xxx'cr'
+5_xxx'cr'
+12_xxx'cr'
-12_xxx'cr'
ST_xxx'cr'
MODE_xxxxxx'cr'
SFLT_xx'cr''lf']
Monitor & Control Module (OK/FLT)
Data Interface/Overhead Module (OK/FLT)
Battery/Clock (OK/FLT)
+5V Power Supply (OK/FLT)
+12V Power Supply (OK/FLT)
-12V Power Supply (OK/FLT)
Self Test (OK/FLT)
Mode (LOCAL or REMOTE)
Number of stored faults logged (0 to 10)
The common equipment status command causes a block of data
to be returned which indicates the status of the common
equipment.
5.5.3 E
RROR
P
ERFORMANCE
Parameter Type Protocol Description
Raw BER Command:
Response:
>add/RBER_xm.mE-ee'cr''lf']
Where:
x = < or > (data modifier to indicate that the error rate is less than
or greater than the returned value).
m.m = 1.0 to 9.9 (error rate mantissa).
ee = 1 to 99 (error rate exponent).
Notes: 1. The 'x' (< or >) parameter is only returned if the error
rate has exceeded the computational resolution of the
system.
2. No Data' is returned if the error rate cannot be
calculated.
3. 'Sampling' is returned if not enough data is currently
available to calculate the error rate.
