CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
60
DISPLAY SELECTIONS/DESCRIPTION
TX-IF FREQUENCY
1200.0000 MHz
950 to 1750 MHz (in 100 Hz steps).
* non TX/RF L-Band modem (non-terminal
frequency mode) only.
or
TX-IF FREQUENCY
5845.0000 MHz
Range dependent on LO and Mix (in 1 MHz
steps).
* non TX/RF L-Band modem (terminal
frequency mode) only.
TX-IF OUTPUT
OFF
ON, OFF.
TX POWER LEVEL
+5.0 dBm
-5.0 to –30.0 dBm (normal range)
+5.0 to –20 dBm (high power option)
*non TX/RF L-Band modem only
TX POWER LEVEL
-10.0 dBm
0.0 to –40.0 dBm
*TX/RF L-Band modem only
SCRAMBLER
ON
ON, OFF
DIFF. ENCODER
ON
ON, OFF
CARRIER MODE
NORMAL-MODULATED
NORMAL-MODULATED
CENTER-CW
OFFSET-CW
DUAL-CW
MODEM REFERENCE
INTERNAL
INTERNAL
EXT1MHz
EXT5MHz
EXT10 MHz
EXT 20 MHz
OUTPUT 10MHZ – (High Stability option only)
