background image

CDM-IP 300L IP-Centric Satellite Modem

Rev. 1

CD/CDMIP300L.IOM

222

8.3.4.1 T

HE

TCP C

ONNECTION

T

ABLE

The tcpConnTable is a table containing TCP connection-specific information. Each row
contains information about a particular current TCP connection. A row is transient, in
that it ceases to exist when the connection makes the transition to the CLOSED state.

Table 30. TCP Connection Table OIDs

OID Description

tcpConnLocalAddress

Local IP address for this TCP connection. In the case of a
connection in the listen state which is willing to accept
connections for any IP interface associated with the node, the
value 0.0.0.0 is used.

tcpConnLocalPort

Local port number for this TCP connection.

tcpConnRemAddress

Remote IP address for this TCP connection.

tcpConnRemPort

Remote port number for this TCP connection.

tcpInErrs

Total number of segments received in error.

tcpOutRsts

Number of TCP segments sent containing the RST flag.

8.3.5 UDP G

ROUP

This group contains control parameters and statistics for the UDP protocol. This group
contains a UDP table describing the UDP ports in use.

Table 31. UDP Group OIDs

OID Description

udpInDatagrams

Total number of UDP datagrams delivered.

udpNoPorts

Total number of received UDP datagrams for which there was no
application at the destination port.

udpInErrors

Number of received UDP datagrams that could not be delivered for
reasons other than the lack of an application at the destination
port.

udpOutDatagrams

Total number of UDP datagrams sent from this entity.
