Comtech EF Data CDM-IP 300L - Manual (Page 92)

CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
66
4.2.1.1.1.6 Configuration - Recall
DISPLAY SELECTIONS/DESCRIPTION
CONFIGURATION
RECALL
CONFIGURATION #1
RECALL
The Configuration Recall menu allows the
user to recall a previously saved configuration
setup. Upon entry, select memory location 1
through 5 by pressing [
↑] or [↓]. Press
[ENTER] to execute the recall.
4.2.1.1.2 Function Select – Monitor
DISPLAY SELECTIONS/DESCRIPTION
FUNCTION SELECT
MONITOR
RAW BER
CORRECTED BER
RECEIVE SIGNAL
SWEEP FREQ
BUFFER FILL
TX-RS N/K DEPTH
RX-RS N/K DEPTH
LNB CURRENT
ODU CURRENT
4.2.1.1.2.1 Monitor – Raw BER
DISPLAY SELECTIONS/DESCRIPTION
RAW BER
No Data
Displays the current BER or “No Data” (if
carrier is not locked).
Range: < m.m E-e to > m.m E-e.
Note: Low limit is based on performance.
High limit is based on data/code rate.
4.2.1.1.2.2 Monitor – Corrected BER
DISPLAY SELECTIONS/DESCRIPTION
CORRECTED BER
No Data
Displays the current corrected BER or “No
Data” (if carrier is not locked).
Range: 1.0 E-3 to 1.0 E-12.
Note: Low limit is based on performance.
High limit is 1.0 E-12.
