CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
1
1 Introduction
CDM-IP 300L
Satellite
Modem
1.1 I
NTRODUCTION
The CDM-IP 300L, hereafter referred to as the CDM-IP, is a high-performance, low-cost,
IP-Centric satellite modem designed for closed network Single Channel Per Carrier
(SCPC) links. It is ideal for many VSAT applications. Offering a range of data rates from
2.4 kbps to 5.0 Mbps in 1 bit per second steps, the modem includes Viterbi forward error
correction as standard. The Turbo Product Codec is available as an option.
The modem is compact, 1U high and 12 inches deep, and consumes only 25 Watts
typically. It has the following configuration and control capabilities:
Front panel VFD display and keypad for local configuration and control.
Rear panel Remote Control Serial interface (DB9) for modem configuration and
control.
Rear panel Console Port (RJ-11) for Ethernet interface configuration and control.
Rear panel Ethernet Data interface (RJ-45).
For initial operation and setup, refer to 12, Quick-Start Guide.
