CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
255
8.6.1.8 L
OGS
Table 61. Logs OIDs
OID Description
cdmip300LClearEventsLog Instructs the unit to clear all Stored Events. A
value of 1 (yes) is used to clear the event log.
cdmip300LNumberUnreadEvents Returns the number of Stored Events which remain
unread. The value can be between 0 and 99.
cdmip300LRetrieveNext5Events Unit returns the oldest 5 Stored Events which have
not yet been read over the remote control. Reply
format: {CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body,
where Sub-body= ABCddmmyyhhmmss,
A being the fault/clear indicator: F=Fault, C=Clear,
I=Info.
B being the fault type where: 1=Unit, 2=Rx Traffic,
3=Tx Traffic, 4=Power on/off, or log cleared.
C being the fault code, where the Info codes are:
0=power off, 1=power on, 2=log cleared, 3=global
config change, and 4=redundancy config change.
ddmmyyhhmmss = date/time stamp.
If there are less than 5 events to be retrieved, the
remaining positions are padded with zeros.
cdmip300LSetStatisticInterval Used to set the sample interval for the Statistics
Logging Function. Can be set to:
0 None
1 10 Mins
2 20 Mins
3 30 Mins
4 40 Mins
5 50 Mins
6 60 Mins
7 70 Mins
8 80 Mins
9 90 Mins
cdmip300LClearStatisticsLog Instructs the unit to clear all Stored Statistics. Can
be set to 1 (yes) to clear the log.
cdmip300LNumberUnreadStatistics Returns the number of Stored Statistics which
remain unread. Can be between 0 and 250.
