CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
239
OID Description
cdmipParamconfig Identifies the PARAM file that will be loaded on
bootup. The options are:
Last saved Parameter file
Factory – uses the internal, hard-coded factory
default parameters.
cdmipUnitInformation Displays unit current operational software
information.
cdmipBootImageInfo Displays unit current Boot Image software
information.
cdmipAppImage1Info Displays Application Image 1 software information.
cdmipAppImage2Info Displays Application Image 2 software information.
cdmipFramerVersion Displays Framer module version information.
8.5.2.6.1 Remote Port B Configuration Subgroup
This subgroup defines the Remote Port B configuration.
Table 47. Remote Port B Configuration Subgroup OIDs
OID Description
cdmipRemotePortBDeviceAddress Defines the device address. Valid addresses are in
the range from 0 to 9999.
cdmipRemotePortBBaudRate Defines the speed of the serial interface.
Can be set to:
1 1200
2 2400
3 4800
4 9600
5 19200
6 38400
cdmipRemotePortBFormat Supports three configurations for the Remote Port B
interface. Each format defines a triple that describes
the data bits, parity, and stop bits.
Can be set to:
1 8-N-1 (8 data bits, no parity, 1 stop bit)
2 7-E-2 (7 data bits, even parity, 2 stop
bits)
3 7-O-2 (7 data bits, odd parity, 2 stop
bits)
