DISPLAY SELECTIONS/DESCRIPTION
TEST MODE STATUS
-------
Test mode status indicator. The following
modem test points are listed and display a
“+” when a test mode is active:
• RS CORR OFF
• INTRFC LOOP BACK
• B-BAND LOOP BACK
• CARRIER MOD
LAMP TEST ??
PRESS ENTER
Lamp test function. Press [ENTER] to turn
the front panel indicators on for three
seconds
SELF TEST
OFF
Select OFF, AUTO, or RUN. After
completion of the test, SELF TEST
(“PASSED” or “FAILED”) is displayed.
• OFF bypasses built-in self test.
• AUTO initiates built-in self-test when
turning on modem.
• RUN initializes self test.
DISPLAY CONTRAST
LEVEL: 50
Set display Contrast
1 - 99
M&C FIRMWARE
FW/8460-1N
Displays the M&C module firmware version.
Press [ENTER] to display the month, day,
and year.
BOOT FIRMWARE
FW/8699-
Displays the Boot firmware version. Press
[ENTER] to display the month, day, and
year.
FPGA FIRMWARE
FW/9540A
Displays the FPGA firmware version. Press
[ENTER] to display the month, day, and
year.
CDM FIRMWARE
FW/XXXX
Displays the CDM firmware version. Press
[ENTER] to display the month, day, and
year.
