CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
244
8.5.2.6.6 Compression Statistics
Note: This subgroup will only be accessible in the MIB tree if the Header and/or Compression
FAST feature has been purchased and activated. Otherwise, both GETs and SETs on
these OIDs will return errors.
This subgroup contains the Compression statistics elements. This is implemented as a
table with maximum number of configured QoS rules, as the rows.
Table 52. Compression Statistics Subgroup OIDs
OID Description
cdmipCompressionStatisticsEntry Queue index of this particular row in
the compression stats table.
cdmipHdrcompStatsQueueIndex Queue index of this particular row in
the header compression stats table.
cdmipHdrcompStatsPreHdrCompBytes This counter keeps track of bytes in
full packet before header
compression.
cdmipHdrcomStatsPostHdrCompBytes This counter keeps track of size in
bytes of the packet after doing
header compression on the packet.
cdmipHdrcompRatio Displays effective header
compression ratio.
cdmipPayloadCompStatsPrePayloadCompBytes This counter keeps track of bytes in
full packet before payload
compression.
cdmipPayloadCompStatsPostPayloadCompBytes This counter keeps track of size in
bytes of the packet after doing
payload compression on the packet.
cdmipPayloadCRatio Displays effective payload
compression ratio.
cdmipHdrcompStatsResetCounters Resets all header compression
counters associated with specified
QoS rule/queue.
8.5.2.6.7 QoS Rules Subgroup
Table 53. QoS Rules Subgroup OIDs
OID Description
cdmipQoSFeature QoS feature status
cdmipQoSRulesTable
cdmipQoSRulesEntry
