Comtech EF Data CDM-IP 300L User Manual
Page 274
CDM-IP 300L IP-Centric Satellite Modem
Rev. 1
CD/CDMIP300L.IOM
248
OID Description
cdmip300LTxModType
Transmit modulation type. Valid values are:
1 BPSK
2 QPSK
3 OQPSK
cdmip300LTxFECType
Transmit forward error correction coding type. Valid values
are:
0 None
1 Vit
2
Turbo Q 3/4
3
Turbo B 21/44
4
Turbo B 5/16
5 Turbo
OQ3/4
6
Turbo Q 1/2
cdmip300LTxFECCodeRate Transmit forward error correction code rate. Can be set to:
1 Rate
1/2
3 Rate
3/4
7 Rate
7/8
8 Rate
21/44
9 Rate
5/16
cdmip300LTxSpecInv
Transmit spectral inversion selection. Can be set to:
0 Normal
1 Inverted
cdmip300LTxScrambler
Transmit scrambler state. Can be set to:
0 Off
1 On
cdmip300LTxClockSource
Transmit clock source. Can be set to:
1 Internal
2 External
3 LoopTmed
cdmip300LTxPowerLevel
Transmit output power level. Can be set from 0 to –200. The
units are 0.1 dBm (0 = 00.0 dBm to -200 = -20.0 dBm).
