Comtech EF Data CDM-IP 300L - Manual (Page 135)

CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
109
Parameter Type Protocol Description
RSDE_xxx'cr'
RDA_xxx'cr'
RRSI_xx'cr'
LNB_xxx’cr’
LNBV_xxx’cr’
LNBR_xxx’cr’
LNBL_xxx’cr’
LNBH_xxx’cr’’lf’] Reed-Solomon Decoder
Receive BPSK Data Ordering
RX Reed-Solomon Interleave Value
LNB Power
LNB Voltage
LNB Reference
LNB Current Monitor Low Current Threshold
LNB Current Monitor High Current Threshold
This command is used by the EF Data M:N protection switch to
collect information that is necessary to configure back-up
modems. Because this command (content and/or order) can be
changed at any time by EF Data, it is advisable that other
commands ('DCS_' and 'ICS_', or 'BCS_') be used for M&C
systems.
Interface
Config
Status Command:
Response:
>add/ICS_'cr'
ITOT_xxxxx'cr'
IROT_xxxxx'cr'
Interface Transmit Overhead Type
Interface Receive Overhead Type
Where: xxxxx = NONE*
*NOTE: CDM-IP 300L only
The Interface configuration status command causes a block of
data to be returned by the addressed MODEM. The block reflects
the current configuration of the interface. Additional configuration
status of new options and features will always be appended to the
end.
MODEM
Faults Status
(Summary)
Command:
Response:
>add/MFS_'cr'
DMD_xxx'cr'
MOD_xxx'cr'
TX_xxx'cr'
IRX_xxx'cr'
CEQ_xxx'cr'
ODU_xxx'cr'’lf']
Demodulator (FLT/OK)
Modulator (FLT/OK)
Interface Transmit Side (FLT/OK)
Interface Receive Side (FLT/OK)
Common Equipment (FLT/OK)
ODU (FLT/OK)
Modulator
Status
Command:
Response:
>add/MS_'cr'
RF_xxx'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
SCT_xxx'cr'
EXT_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
RF Output (ON/OFF) actual status not config
Module (OK/FLT)
IF Synthesizer (OK/FLT)
Data Clock Synthesizer (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
AGC Level (OK/FLT)
Modem Reference PLL Lock (OK/FLT)
Modem Reference Activity (OK/FLT)
Configuration (OK/FLT)
Number of stored faults logged (0 to 10)
Demodulator
Status Command:
Response:
>add/DS_'cr'
MOD_xxx'cr'
CD_xxx'cr'
SYN_xxx'cr'
ICH_xxx'cr'
Demod Module (OK/FLT)
Carrier Detect (OK/FLT)
IF Synthesizer Lock (OK/FLT)
I Channel (OK/FLT)
