CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
261
OID Description
OduUnitFaults Used to Query the Alarm status of the CSAT. An integer
value will be returned between 0..262143 where the bits
that are set indicate the faults which have occurred:
bit 0 24 volt power supply
bit 1 20 volt power supply
bit 2 12 volt power supply
bit 3 10 volt power supply
bit 4 +5 volt power supply
bit 5 -5 volt power supply
bit 6 Tx Synthesizer Unlocked
bit 7 Tx IFLO Unlocked
bit 8 Rx Synthesizer Unlocked
bit 9 Rx IFLO Unlocked
bit 10 Reference lock detect
bit 11 LNA Current Alarm
bit 12 Fan Current Alarm
bit 13 Temperature Alarm
bit 14 HPA Thermal Shutdown Alarm
bit 15 Internal IIC Bus Alarm
bit 16 EEPROM Checksum
bit 17 NVRAM/RTC Low Battery Alarm
8.6.1.15 ODU L
OGS
Table 67. ODU Logs OIDs
OID Description
oduClearEventsLog Can be set to 1 (yes) to issue command.
oduNumberUnreadEvents CSAT returns the number of Stored Events which remain
unread. Value can be between 0 and 99.
oduRetrieveNext5Events CSAT returns the oldest 5 Stored Events that have not yet
been read over the remote control. Reply format: Sub-
body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body,
where Sub-body=YYYYYYYYYY ZZ mmddyyhhmmss,
YYYYYYYYYY being the fault description.
ZZ being the alarm type: FT = Fault, OK = Clear, IF =
Information.
mmddyyhhmmss = date/time stamp.
