CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
259
8.6.1.13 ODU R
X
P
ARAMETERS
Table 65. ODU Rx Parameters OIDs
OID Description
OduRxFrequency Receive frequency in KHz. Can be between 3,625,000 KHz
and 14,100,000 KHz.
oduRxAttenuation Receive attenuation. Can be between 0..2500 in 0.01dB
where 0=0.00dB to 2500=25.00dB.
oduRxMute Receive mute. Can be set to:
0 Disabled
1 Enabled
oduRxSlopeMode Receive slope mode. Can be set to:
0 Manual
1 Calibrated
oduRxSlopeValue Receive slope value. Can be between 0..10 in 0.1, where
0=0.0 to 10=1.0.
oduRxGainOffset Receive gain offset. Can be between -400 and 0 in 0.01 dB,
where 0=0.00 dB to -400 = -4.00dB
