CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
157
6.2.3.1 Q
O
S C
ONFIGURATION
P
AGE
– M
AX
/P
RIORITY
M
ODE
The QoS Rules Configuration page is activated from the QoS Configuration page.
The QoS Rules Configuration page contains the following options/fields when in Max/Pri Mode:
Menu Options/Fields Entry Description
Rule 01 – 08 (32)
(The 8 currently displayed
QoS Rules, up to 32 can be
defined).
By selecting a QoS Rule,
the user will be asked to
define the following:
1 - 08 Max/Pri QoS can be assigned to up to 32 different types
of flows to be defined by the user. Flows can be defined
by any combination of Protocol (FTP, UDP, RTP, etc.),
Source/Destination IP (specific or range), and/or Layer 3
Source/Destination Port.
See Section 1.4.4.1 Maximum Bandwidth/Priority
Mode for a more detailed description of this QoS option.
