CDM-IP 300L IP-Centric Satellite Modem
Rev. 1
CD/CDMIP300L.IOM
311
12.2.3 S
ETTING
IP A
DDRESS
(
ES
)
Step Description
1
From the Main Menu select Interface Configuration sub-menu [I].
2
From the Interface Configuration Menu select Ethernet Interface (fei0) sub-menu [E].
3
Set IP Address [I].
CDM-IP 1 to 172.16.10.1
CDM-IP 2 to 172.16.10.2
4
Set Subnet Prefix Length [M] to 24
The other parameters can be left to their factory default settings.
At this point the basic configuration is over and you should be able to:
5
From PC1
Ping 172.16.10.1 (CDM-IP 1)
Ping 172.16.10.2 (CDM-IP 2)
Ping 172.16.10.12 (PC 2)
6
From PC2
Ping 172.16.10.2 (CDM-IP 2)
Ping 172.16.10.1 (CDM-IP 1)
Ping 172.16.10.11 (PC 1)
IMPORTANT
Do not enable IF Loopback (or link the TX to RX by a BNC cable or satellite link) on a
CDM-IP modem operating in easyConnect
when connected to a LAN. In this
configuration, easyConnect
will resend all layer 2 broadcast packets and cause a
“broadcast storm” on the LAN.
