DISPLAY SELECTIONS/DESCRIPTION
MOD POWER OFFSET
0.0 dB
Modulator power offset adjust. Offsets the
modulator output power readout in the
Configuration menu. This feature does not
actually change the modulator power level,
but displays an offset value in the monitor.
The modulator power offset range is -99.9 to
+99.9 dB, in 0.1 dB steps.
Note: Anything except 0.0 dB will cause ADJ
to be displayed for the TX power level
ENCODER TYPE
VITERBI
Select Encoder type
VITERBI
SEQUENTIAL
TURBO (Only in Custom mode)
SCRAMBLER
EFD MOD V.35
Select Scrambling type
INTELSAT
V.35
TX BPSK ORDERING
STANDARD
Select BPSK Bit Ordering
STANDARD
NON-STANDARD
MOD SPECTRUM
NORMAL
Select TX spectrum phase
NORMAL
INVERT
TX-RS N/K DEEP
8 DEEP
Select Reed-Solomon Interleaver Depth
4
8
16
TX IESS-310 MODE
OFF
Selection of IESS-310 compliance for 8-PSK
2/3 with Reed-Solomon
ON
OFF
ODU ALARM LOW
0 mA
Set ODU low current alarm threshold
X.X mA
ODU ALARM HIGH
0 mA
Set ODU high current alarm threshold
X.X mA
