Character 'j': Interface receive side faults character 1.
Bit 6 = 1 always.
Bit 5 = Insert fault.
Bit 4 = reserved.
Bit 3 through Bit 0 = Binary representation (0 to 10) of the number of
interface receive side stored faults.
Character 'k': Interface receive side faults character 2.
Bit 6 = 1 always.
Bit 5 = Buffer Underflow.
Bit 4 = Buffer Overflow.
Bit 3 = Receive Data Loss/AIS.
Bit 2 = Frame BER.
Bit 1 = Receive Backward Alarm.
Bit 0 = Selected Buffer Clock Activity.
Character 'l': Interface receive side faults character 3.
Bit 6 = 1 always.
Bit 5 = Buffer Clock PLL Lock.
Bit 4 = Demux Lock.
Bit 3 = 2047 Pattern Lock Detect.
Bit 2 = Buffer Full.
Bit 1 = reserved.
Bit 0 = Configuration.
Character 'm': Interface receive side faults character 4.
Bit 6 = 1 always.
Bit 5 = RX Audio Channel 1 Clip.
Bit 4 = RX Audio Channel 2 Clip.
Bit 3 = reserved.
Bit 2 = reserved.
Bit 1 = reserved.
Bit 0 = reserved.
Character 'n': Common equipment fault status character 1.
Bit 6 = 1 always.
Bit 5 = Monitor & Control Module.
Bit 4 = Interface Module.
Bit 3 through Bit 0 = Binary representation (0 to 10) of the number of
common equipment stored faults.
Character 'o': Common equipment fault status character 2.
Bit 6 = 1 always.
Bit 5 = Battery/Clock.
Bit 4 = +5V power supply.
Bit 3 = reserved.
Bit 2 = +12V power supply.
Bit 1 = -12V power supply.
Bit 0 = reserved.
Character 'p': Interface backward alarm status character 1.
Bit 6 = 1 always.
Bit 5 = TX Backward Alarm 1.
Bit 4 = TX Backward Alarm 2.
Bit 3 through Bit 0 = Binary representation (0 to 10) of the number of
backward alarm stored faults.
Character 'q': Interface backward alarm status character 2.
Bit 6 = 1 always.
Bit 5 = TX Backward Alarm 3.
