4.2 MENUS
4.2.1 M
ENU
T
REE
Figure 10 shows the menu structure of the CDM-IP 300L Front Panel menu. The detailed
screens and menus are described in subsequent paragraphs.
CONFIG URATION
MODULATOR
DEMODULATOR
INTERFACE
LO CAL AUP C
SA VE
RECALL
*
2
2
FUNCTION SELECT
CONFIGURATION
MONITOR
FAULTS/ALARMS
STORED/FAULTS
,
*REMOTE AUPC
UTILITY
2
2 3
3
4
MODULATOR
TX-V OQPSK 1/2
TX -IF FREQUEN CY
TX -IF OUTPUT
TX POWER LEVEL
SCRAMBLER
DI FF. ENCODER
CARRIER MODE
MO DEM REFEREN CE
ODU POWER SUPPLY
ODU 10 MHz REF
RS ENCODER
DEMODULATOR
RX-V OQPSK 1/2
RX -IF FREQUEN CY
DESCRAMBLER
DI FF. DECODER
RF LOOP BACK
IF LOOP BACK
BER THRESHOLD
SW EEP CENTER
SW EEP RANGE
REACQUISITION
LNB POWER
LNB VOLTAGE
LNB 10 MHz REF
RS DECODER
INTERFACE
INTRFC LOOP BACK
MONITO R
RAW BER
CORRECTED BER
Eb/No
RECEIVE SIGNAL
SWEEP FRE QUEN CY
BUFFER FILL
LNB CURRENT
ODU CURRENT
*
AUPC ENABLE
NOMINAL PPOWER
MINIMUM POWER
MAXIMUM POWER
TARGET NOISE
TRACKING RATE
LO CAL CL ACTI ON
REMOTE CL ACTION
* LOCAL AUPC
FS K OUTPUT
OD U OUTPUT DE LAY
CDM-IP 300L Front Panel Menu Tree
(1 Of 5)
*
CONDITIONAL OR
OPTION DE PENDENT
See 1/5
See 2/5
See 3/5
See 4/5
1
2
3
4
See 5/5 5
5 ,
Figure 10. Front Panel Modem Menu Tree (1 of 5)
