CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
253
8.6.1.7 S
TATUS
P
ARAMETERS
Table 60. Status Parameter OIDs
OID Description
cdmip300LRxEbno Value of Ebi/No, can be between 0 and 160 in 0.1 dB
where 0 = 0.0 dB to 160 = 16.0 dB and 999 = Demod
Unlocked
cdmip300LRxCoarseAGC Value of Coarse AGC setting, can be between 0 and
99.
cdmip300LRxFrequencyOffset Value of frequency offset of the carrier being
demodulated.
Can be between -30 KHz and 30 KHz
where -30 = -30 KHz to 30=+30 KHz and 999 =
Demod Unlock.
cdmip300LBufferFillState Value of the buffer fill state. Can be between 0 and
99 in percentage filled.
cdmip300LRxBER Value of the estimated corrected bit error rate. Value
has been
multiplied by 10E
-10
.
cdmip300LRedundancyState Returns the redundancy state of the unit, where: 0 =
Off Line (forced into standby by 1:N or 1:1 Switch);
1= On Line (normal). Valid values are:
0 Offline
1 Online
cdmip300LModemUnitFaults Returns the current fault and status codes for the Unit
(hardware). The value will be a integer between 0
and 8191 where the bit that is set indicates which
fault has occurred:
bit 0 not used, always 0
bit 1 volt power supply
bit 2 12 volt power supply
bit 3 5 volt power supply
bit 4 18 volt power supply
bit 5 12 volt power supply
bit 6 RAM load fail
bit 7 Tx synthesizer unlocked
bit 8 Rx synthesizer unlocked
bit 9 Power cal checksum fail
bit 10 FPGA main chain load fail
bit 11 Turbo FPGA load fail
bit 12 IP Module fail
