CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
179
6.2.7.3 AUPC M
ODEM
C
ONFIGURATION
P
AGE
The AUPC Modem Configuration page is activated from the Modem Parameters page.
The AUPC Modem Configuration page contains the following options/fields:
Note: AUPC Modem Configuration Page is only accessable if AUPC option is available.
Menu Options/Fields Entry Description
Local Modem AUPC Mode O 1 - OFF
2 - ON
Local Modem AUPC Enable A 1 - OFF
2 - ON
Nominal Power Level P Valid range are from –40.0 to –0.0 dB.
Maximum Power Limit M Valid range are from –40.0 to –0.0 dB.
Minimum Power Limit N Valid range are from –40.0 to –0.0 dB.
Maximum Tracking Rate T Valid range are from 0.5 to 6.0, in multiple of 0.5.
Target Eb/No of Remote
Demod (dB) E Valid range are from 3.2 to 16 dB.
Action on Local Carrier Loss L 1 - HOLD
2 - NOM
3 - MAX
