CDM-IP 300L IP-Centric Satellite Modem Rev. 1
AUPC CD/CDMIP300L.IOM
304
To setup the modem for the self-monitoring operation, enter the Local Modem AUPC
menu located under the Utility Modem Type menu and select On. This enables the
Configuration: Local AUPC menu to permit adjustment of the AUPC parameters
described in Table 23.
Notes:
1 Comtech EF Data does not recommend increasing the power to the satellite without
consulting with the satellite controller.
2 Be careful not to set carrier output too high when there is a loss of carrier due to
severe weather and the CL loss action is set to Maximum.
3 Do not use the distant end RX signal to compensate for local rain fade unless
allowances are made for a narrow window for TX level changes.
11.1.5 F
RONT
P
ANEL
O
PERATION
For information on the additional front panel operations that are specific to the ASYNC
interface. The following menus are affected:
Configuration Local AUPC
Remote AUPC Configuration
Remote AUPC Monitor
Table 72. AUPC Default Settings
Local AUPC
AUPC ENABLE OFF Target Noise 6.0 dB
Nominal Power +0.0 dBm Tracking Rate 0.5 dB/MIN
Minimum Power -20.0 dBm Local CL Action Hold
Maximum Power +5 dBm Remote CL Action Hold
